L5200mm Aluminum Bus Shelter

    Buy cheap L5200mm Aluminum Bus Shelter from wholesalers

    Buy cheap L5200mm Aluminum Bus Shelter from wholesalers
    • Buy cheap L5200mm Aluminum Bus Shelter from wholesalers

    L5200mm Aluminum Bus Shelter

    Ask Lasest Price
    Brand Name : PHAROS—ShiJiTaiLai
    Model Number : E011
    Certification : ISO9001,ISO14001,OHSAS18001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 200set/month
    Delivery Time : about 15 work days
    • Product Details
    • Company Profile

    L5200mm Aluminum Bus Shelter

    Outdoor Furniture Solar Powered Aluminum Bus Shelter Led Solar Bus Shelter



    1. product detail

    Bus shelter roof:
    1. The supporting bow of the bus station is made of 3.0mm-thick carbon steel plate, phosphatized and spray molded.
    2. The top frame of bus shelter is made of 1.5mm and 2.0mm carbon steel laser and sheet metal.
    3. 8 mm PC solar panel is used for sun shading and rain protection at the top of bus station, and 1.0 stainless steel batten is used for fixation of PC solar panel.
    Column of bus shelter:
    1. 3.0mm-thick 150 mm × 150 mm galvanized pipe is used for bus station column, and spray plastic treatment is adopted for general situation.
    2. Adjustable movable base plate is used for the column base of bus platform to correct the parallelism.
    3. The column is connected with the light box and the top supporting bow with stainless steel bolts.
    Light Box:
    1. The bus platform box body adopts 1.5mm-thick galvanized plate, and the general situation is processed by spraying plastic.
    2. The box is equipped with LED light source spotlight.
    3. 1.0mm-thick galvanized sheet is used for the lamp bracket, and the general situation is treated by spraying plastic.
    5. Each station is equipped with Delixi leakage switch and OMAX time control switch assembly.
    Frame:
    1. The outer frame is made of 1.5mm-thick galvanized steel plate, which is generally treated by spray molding.
    2. The transparent plate is made of 6.0mm thick transparent toughened glass.
    3. K-type 3 × 10 waterproof and dust-proof cushion rubber is used for the combination of transparent board and outer frame of bus platform.
    4. Gradient lace is set on the transparent board.
    5. The inner periphery of the outer frame is provided with a cloth drawing device.
    Coordination between the box body and the outer frame of the bus shelter:
    1, The box body and the outer frame are connected by hinges.
    2. D-type 5 × 10 waterproof and dustproof sealant strip shall be added for the coordination of box body and outer frame.
    3. When the outer frame of the bus station is opened, it is fixed by the hydraulic steam strut, and when it is blocked, it is fixed by the anti-theft trunk lock.
    Bench:
    1. The seats and stools are made of 1.5mm and 2.0mm galvanized sheet metal, and are treated with plastic spray.
    7, Embedded parts of bus shelter Foundation:
    1. The plate is made of 10.0mm thick 300 mm × 300 mm × 1 carbon steel plate.
    2. The vertical steel adopts φ 18 × 600mm × 4 pieces of threaded steel.
    3. The connection between the flat plate and the vertical steel adopts electric welding.
    Proportion and pouring of foundation concrete of bus platform:
    1. Concrete ratio: 1:3:4.
    2. The concrete is poured in two times.
    All bolts (except anchor bolts) of bus station are made of stainless steel.


    Sichuan century Tailai Metal Technology Co., Ltd. is engaged in the production, development and production of public transport shelters, light boxes, metal products manufacturers, providing stainless steel bus shelters, intelligent bus waiting kiosks, etc.


    Here is the size and side view of this Outdoor Furniture Solar Powered Aluminum Bus Shelter Led Solar Bus Shelter​



    2. Specification



    Item name

    Outdoor Furniture Solar Powered Aluminum Bus Shelter Led Solar Bus Shelter

    size
    L4500*W2000*H3000mm
    Material
    Frame
    Aluminum/ Stainless Steel /Galvanized steel
    Panel
    PC/tempered glass
    Light Source
    LED lamp
    Base
    Galvanized Sheet
    Frame color

    Aluminum silver, black or other custom- color

    Additional features
    Solar plant , LED display,WIFI,USB,monitor
    Package
    with air bubble and cotton inside, individual plywood carton outside


    Key features
    • Environmentally friendly materials used, bright homogeneous LED light distribution
    • Strong, Vandal-resistant,weather-proof housing design,excellent waterproof performance, safe and reliable power system.
    • Flexible design, suit for either led screen face or led light box face.
    • All components of the product can be processed according to customer requirements.
    Applications Guide

    Streets lighting

    Boardwalks
    Public parks
    Private gardens
    Access roads
    Walking paths
    Bus stations

    3. Product processing




    4. Customer visit



    Customer Visit and Cooperation

    Our products are sold through out the world, The foreign customers are very kind to visit our company/factory and negotiate business face to face.

    We will surely make our best effort to provide best solution and service.



    Black from Brazil visited the company to inspect the bus shelter projectDiscussion meeting, put forward suggestions and opinions on technical problems of bus sheltersMeeting, negotiation, agreement, cooperation and mutual win.
    Dubai Abu Dhabi customer conference negotiationSite inspection and evaluation of the plantTechnical director guides technical problems on site

    5. Product application



    L5200mm Aluminum Bus Shelter

    Modern Design Bus Stop Shelter With LED Display Advertising Light Box

    Stainless steel modern bus station shelter design

    Led Outdoor Advertising Metal Aluminum Bus Shelter Modern Bus Station Shelter

    size:L4000*W1518*H2400
    Main material:Galvanized,steel

    size:L3500*W1600*H2915
    Main material:stainless steel,tempering glass

    size:L7000*W1650*H2915
    Main material:Galvanized steel

    L5200mm Aluminum Bus Shelter

    Customized Smart Bus Shelter City Furniture Public Facility Intelligent

    Modern bus shelter

    Smart City Advertising Solar Bus Shelter Furniture Public Facility Bus Shelter

    size:L3000*W1600*H2800
    Main material:Galvanized steel

    size:L3500*W1518*H2915
    Main material:stainless steel

    size:L5000*W1600*H2915
    Main material:Aluminum profile


    Case Show:



    6. Our Certificate




    For more information, please just feel free to contact us.



    Online service: To reply your questions within 24 hours.

    Sample Test: The sample is provided for trial, but it is not free. The sample could be made first for batch order.

    Installation: Professional construction drawings and guidance from professionals are provided.



    Q:what size of the product?
    The size of poster is available for customized as to your special requirement.

    Q: Are you trading company or manufacturer ?

    A: We are factory.

    Q: How long is your delivery time?

    A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

    Q: Do you provide samples ? is it free or extra ?

    A: we do not offer free sample,but will refund the difference to the buyer once batch order is confirmed.


    【Poster scenery】- building intelligent bus shelter
