Outdoor Indoor Advertising Double Side Scrolling System Light Box For Advertising

1. product detail

Scrolling light box system Scrolling light box production system is the main accessory of Scrolling advertising light box, which is related to the normal operation of the light box, but in the daily work process, Scrolling system inevitably has some faults, so how to solve these faults.

1. If the Scrolling system fails to start, first check whether the line is normally powered and whether the input voltage is too low. Generally, the Scrolling system of the manufacturer requires that the input voltage should not be lower than 23 v. (this number should be checked in the original manufacturer's Manual of the Scrolling light box manufacturer.) if the power supply is normal, check whether the system setting is normal and whether the set advertising screen change interval is too long If the system is set to the slave state in a long-term or wrong way, if the setting is normal, check whether the motor is faulty. If the motor is burnt out, the production of the bus shelter needs to be reordered from the original Scrolling light box manufacturer, because generally, the system configured by each manufacturer is different, and the motor specifications and parameters will also be different.

2: When the Scrolling system stops Scrolling, the advertising picture displayed in the light box is not a complete poster, but two posters appear at the same time and are not complete. The details are as follows: it must be adjusted when the system is working normally, otherwise it will not work, and attention should be paid to the up and down direction when adjusting The first advertising screen close to the upper scScrolling axis shall be adjusted upward, whereas the last advertising screen close to the lower scScrolling axis shall be adjusted downward. If this operation is not followed, the system will automatically determine that the adjustment is invalid, which is equivalent to doing idle work.

3: There is left and right deviation phenomenon in the advertising picture. There are two reasons for the production of the advertising light box, which may be that the position of the upper and lower axes of the Scrolling system is not accurate enough, because the system requires that the axis lines of the upper axis and the lower axis must be in the same plane and parallel, so as to ensure the correct position of the advertising picture. At this time, the position of the roller mounting base can be adjusted to solve the problem. Another reason is that It can be caused by improper selection of canvas materials, because some materials have large flexibility of canvas, even if the system is adjusted properly, it can not guarantee the correct picture position. It can replace with better canvas materials, and the canvas width should be appropriately shorter than the roller length.

Because the Scrolling system of the light box is in the non-stop operation state, it is also the place where the Scrolling light box is prone to failure. Generally, it is necessary to do a good job of tracking inspection and eliminate the failure in time in order to avoid affecting the advertising effect of the manufacturer.

Here is the size and side view of this Advertising Double Side Scrolling System Light Box

2. Technical parameter

Solar system:

The name of the function Function description Solar power supply Convert solar energy into electricity to save electricity Wife users can connecte wift hotspots through the intelligent equipment Camera Monitor the situation Video Play advertising Mobile phone charging Provide standard USB interface, can charge for smart phone and PAD Led display advertising Scrolling system light box can install,change 5-6 picture

3. Product processing

4. Customer visit

Black from Brazil visited the company to inspect the bus shelter project	Discussion meeting, put forward suggestions and opinions on technical problems of bus shelters	Meeting, negotiation, agreement, cooperation and mutual win.
Dubai Abu Dhabi customer conference negotiation	Site inspection and evaluation of the plant	Technical director guides technical problems on site

Customer Visit and Cooperation

5. Product application

Aluminum Moving Picture Led Floor Standing Light Box Advertising Scrolling Light Box	Modern Home Publicity Floor Standing Light Box Photo Double Sided Advertising Light Box Sign	Vertical Poster Frame Floor Standing Light Box Led Light Box For Outdoor Advertising
Tempered Glass Floor Standing Light Box With Road Sign Light Box	Modern Aluminum Road Floor Standing Light Box Board Scrolling Mupi Double Sided	Outdoor Floor Standing Advertising Scrolling Light Boxes With Modern Design And Best Quality

Case Show:

6. Our Certificate

For more information, please just feel free to contact us.

Q:How many posters can it diplay?
A:3-5 posters per sided, according to the size.

Q:what size do you have?
A:Size can be customized, the biggest size 6x3m. I will suggest you chose small size, because if the higher than 2.3m, we need open top container to transport, the sea freight is hign.

Q:Do you have MOQ?
A: No MOQ, but LCL is not convenient.

 TEL：+86 15982073193

Sichuan Shijitailai Metal Technology Co. , Ltd.（Chengdu xintailai Stainless Steel Engineering Co., Ltd.）was founded in March 2007, with a registered capital of 10 million yuan, and has grade III steel structure professional contracting and safety production license. Focusing on the production and construction of supporting projects of public transport platform projects in large and medium-sized cities, after 13 years of concentrated development, it has been on the road to build a professional manufacturer of intelligent public transport platform in China. With the trend of global economic sharing and the comprehensive development of solar platform technology, the company began to go to the world with strong technical strength.

The company is based in Chengdu, facing southwest and radiating all over the country. [xintailai waiting booth] the platform project covers more than 200 regions, including southwest, northwest, central China, North China and South China. The coverage rate of cities above county level in Sichuan Province reaches 80%, the continuous customers reach 70%, and the customer satisfaction reaches 100%. All projects by virtue of the company's strong and perfect technical strength are high-quality, efficient, stable and continuous service to win customers praise and mutual recommendation!
